Electrolytic Copper Foil Used for Li Ion Battery Anode Current Collector
DESCRIPTION:
ED copper foil for battery anode material
This copper foil is used as a substrate for coating anode materials in Li-Ion battery research.
Copper foil for battery anode substrate |
||
Item |
Data |
|
width (mm) |
280 mm, other width can be customized |
|
Thickness (um) |
8 um / 9 um /10 um, other size optional |
|
areal density (g/m2) |
85-90 |
|
Purity(%) More than 99.9% |
Cu ≥99.9% |
|
Fe < 0.0010% |
||
Bi < 0.00020% |
||
Pb < 0.0005% |
||
Tensile strength (MPa) |
≥294 |
|
Normal elongation(%) |
2.5 |
|
High temperature Tensile strength180℃(MPa) |
≥147 |
|
High temperature elongation180℃(%) |
2 |
|
Anti oxidization(180℃ Heating 1h) |
No oxidation of points on the surface,The color does not change,Copper foil without fracture |
|
Surface roughness(um)Rz |
Drum side(um) |
Less than 0.3 |
Matte side(um) |
Less than 3.0 |
|
Surface tension(dyne/cm) |
Drum side |
62 |
Matte side |
62 |
|
Coating performance |
Cu foil with uniform tension on both sides, slurry coating unifor |
