Layers by Layer

Matte Ink Layer: 3.0 g /m^2 ± 0.5 g/m^2

Biaxially Oriented Nylon (ONy); 6-Nylon: 15 um ± 10%

Adhesive Layer (Carbon Black Mixed): 3.8 g/m^2 ± 1.5 g/m^2

Mat Surface (Treatment Layer)

Soft Aluminum Foil (ALM): 8021 or 8079; 35  um ± 10%

Glossy Surface (Treatment Layer)

Adhesive Resin Layer (PPa): Acid modified PP;20 um ± 10%

Polypropylene (PP): 15 um ± 10%

Glossy Surface (Treatment Layer)

Adhesive Resin Layer (PPa): Acid modified PP;20 um ± 10%

Polypropylene (PP): 15 um ± 10%

Thickness

91 μm ± 10%

Width and Length

Heat Seal Strength

30 N / 15 mm or more

Laminate Strength ONy / ALM

3.0 N / 15 mm or more

Laminate Strength ALM / PP

5.0 N / 15 mm or more

Electrolyte Resistance ALM / PP

Surface quality

Mat finish

Fish Eye

2mm or less in diameter (clear),1mm or less in diameter (colored)

Molding Depth

< 8.0mm

Electrical Insulating

Good

Hot Sealing Condition

180-190°C

Moisture Vapor / O2 Transmission Rate

200ppm / 5 years

Solvent Retention

Less than 5mg/m2
