Description

Product Specification

AC Input

AC 380V±10% 50Hz

Input Power

24KW

Voltage setting range

Charge: 0V~120V Discharge: 3V~120V

Minimum discharge voltage

3V

precision

+0.05% of FS

Output Voltage Resolution

±0.01% of FS

Output voltage ripple

≤0.5% F.S

Channel Features

The constant current and constant voltage source adopts independent double closed-loop structure

Number of main channels

2 channels

Channel control mode

Independent control

Sampling bits

16bit

Current range

Single-channel independent operation: -100A~100A, dual-channel parallel operation: -200A~ 200A

precision

+0.05% of FS

Output current resolution

±0.01% of FS

Constant voltage minimum cut-off current

0.2A

Current response time

Current (10% to 90% Load) hardware response time is less than 10ms

Charge and discharge conversion time

Current (-100% to 100% Load) hardware response time is less than 20ms

Step time range

≤(365*24) hours/step

Resolution

20mS

Data export format

EXCEL, TXT, PDF

Case file import format

EXCEL, TXT

record condition

Minimum voltage interval: 0.24V

Minimum sampling current: 0.2A

Recording frequency: 100Hz

Minimum recording time
