• High-strength hardening steel with hardness of RC > 62

• The roller surface is plated by Cr for anti-corrosive purposes

• Size: 96 mm Dia. x 220mm W

• Note: The benchtop rolling press is not suitable for calendering thick metals. For applications with such needs, please consult with MTI engineers.

Roller Gap

• 0~1.2 mm adjustable

• Note: The gap tolerance may vary with temperature rise as below

• RT-100°C: 0.008 - 0.01 mm

• 100 - 150°C: 0.02 - 0.03 mm

• 150 - 200°C: 0.03 - 0.05 mm

Mechanical Dial Gauge (Included)

• Range: 0 - 3mm

• Accuracy: 0.01mm

Upgradable Digital Micrometer
(Not Included)

• Digital Micrometers are available at an extra cost:

• Range: 0 - 12.7mm

• Accuracy: 0.004mm

• A 0.16mm thick electrode coated on copper can be pressed into a minimum thickness of 0.1 mm

• A 0.06mm thick electrode coated on copper can be pressed into a minimum thickness of 0.04 mm

• A 0.33mm thick silver/gold can be pressed into a minimum thickness of 0.03 mm

• Two digital temperature controllers with 30 segments programmable for control two rollers separately

• 200°C maximum.

• Recommended Heating Rate: 1.3°C/minute

• Two heating elements are installed

• Power of each Heating Element: 1000W total 2000W)

• Temperature Control Accuracy: +/-5°C

• The heating rod is consumable. Please click the picture left to order

Power

• AC 208 - 240V Single phase, 50/60Hz, 2000 W

• Notice: 220V AC Power plug is not included. Please click here to order the plug

• Order a 3000W transformer to use it at 110V, click here to order)

Motor

• High torque motor with a reducing gear, which can run under Ar gas safely

• Rated power 100W

• Digital speed Display: 0~26 mm/s (real linear speed of rollers)

• For 200 mm width Roll to Roll, please consider below R2R device (click picture 1-2 & 3 to order)

• Vertical position rolling can be customized as requested at extra cost. Please refer to picture 4 below

• CE Certified

• NRTL or CSA certification is available upon request at extra cost.

• Please refer to this instruction on how to calculate rolling pressure from roller gap (reference only)

• Analysis of geometric and electrochemical characteristics of lithium cobalt oxide electrode with different packing densities

• Do not touch the surface of the rolling part of the machine when the rollers are heated up or running.

• Due to the influence of working environments, the temperature on the roller surface may be different from the display on the controller. You may calibrate the temperature by TC-calibrator-LD, and refer to the instruction here from time to time to ensure heating temperature accuracy

• Multi-step thickness calendaring needed: While calendaring the sample sheet, make each calendaring decrement of 0.02mm compared with sheet original thickness.

• Never calendaring decrement over 0.02mm compared with the original sheet thickness each calendaring.

• Never roll materials with hardness > 45HRC

• Clean roller surface for each rolling and Use acetone to clean and lubricate when not use to avoid corrosion

• It is not allowed to use any MTI product in any hazardous location, especially prohibited from using in Class I environments (flammable gasses & vapor).
