Heating Rolling Press For Preparing The Li-Ion Battery Electrode Sheet

  • Product Name;Heating Rolling Press
  • Model:AOT-MSK-H2150E
  • Voltage:110VAC/220VAC, 50-60Hz
  • Origin:China
  • Product description: AOT-MSK-H2150E Heated Roller is suitable for Ar glove box and any atmosphere. It is a 150mm wide precision electric rolling machine, the rollers can be heated up to 200°C. Roller press for preparing l
  • INQUIRY

AOT-MSK-H2150E Heated Roller is suitable for Ar glove box and any atmosphere. It is a 150mm wide precision electric rolling machine, the rollers can be heated up to 200°C. roller press for preparing lithium-ion battery electrode sheets and polymer solid electrolyte sheets.

Specification

Product name

Heating Rolling Press

Working Voltage

AC 110  or 220V single phase, 50/60H selectable

Rolling Gap

0 mm ~ 3mm adjustable

Power

1700W output

Pressure

<= 2000 Kg

Rolling Width /Thickness

Thickness 0.005- 2.50 mm

Thickness accuracy: +/- 2 microns

Width135 mm Max.

Rolling Speed

0 ~ 50 mm/ second (Rolling Speed Adjustable)

Forward, Stop, and backward switchable

Control method

Digital controlled with constant power output

Temperature of Rollers

Two rollers can be heated 200°C with a digital temperature controller within +/- 1°C

Digital Micrometer

Range: 0 - 3mm adjustable

Resolution: 0.001mm (or 0.0001in)

Unit interchangeable (mm / in)

Zeroing

Power supply: CR2032 3V Li-battery

Operating temperature: 0 ~ 40°C

Control Panel

Color touch screen panel for setting temperature and speed

Temperature accuracy:  +/- 1°C

Weight

80KG

Heating Rolling Press For lithium BatteryHeating Rolling Press
