  • Digital Touch Screen Viscometer for Battery Slurry Checking Before Coating
Digital Touch Screen Viscometer for Battery Slurry Checking Before Coating

Digital Touch Screen Viscometer for Battery Slurry Checking Before Coating

  • Model: AOT-NDJ-8T
  • Origin: China
  • Range: 1-2 Million mPa.S
  • Measurement accuracy: ±1%
  • Product description: Series T touch screen viscometer is perfectly integrated with the touch screen technology, and the viscosity can be measured with a fashion, modern and high technology rapidly, accurately and directly
  • INQUIRY




Series T touch screen viscometer is perfectly integrated with the touch screen technology, and the viscosity can be measured with a fashion, modern and high technology rapidly, accurately and directly. Various parameters and working conditions can be completely and directly displayed on the 5 inch ultra-large colorful touch screen. Various parameters can be measured, displayed and read directly in high accuracy, the instrument can be displayed conveniently, used to replace similar imported products, and it leads the new trend of science and technology of viscometers made in China.

The main features of the instrument

5 inch full colorful touch screen

- Brand new user's interface
- Enhanced control
- Real-time trend display
- CH/EN operating interface

Displayed information
- Viscosity cp
- Temperature °C
- Dynamic viscosity mm/s2
- Density g/cm3
- Torque %
- Shear rate/ shear stress
- Rotating speed/ rotor

Internal options
- Timed measuring
- Programmable QC upper and lower limit warning
- Automatic measuring range displaying

Item

Performance

NDJ-8S

NDJ-8T

1

Display

LCD

5 inch color touch screen

2

Operation

Touch-button

5 inch color touch screen

3

Measuring range (mPa.s)

1-2,000,000 (2 Million)mPa.S,Use 0-4#Rotor

(Measuring the ultra-low viscosityless than 10mPa.S,need to buy 0# rotor)

4

measurement accuracy

(Newton liquid)

±1%

±1%

5

Repeat accuracy (Newtonian liquid)

±0.5%

6

Speed (r/min)

0.3, 0.6,1.5,3,6, 12, 30, 60

7

Rotor

1#、2#、3#、4# (Standard Parts)

8

Ultra low viscosity adapter

0# (Optional)

9

Display content

10

Viscosity

yes

yes

Temperature

Yes (Need to choose the temperature probe)

Rotor number

yes

Speed

yes

Auto scanning

yes

Thermostatic parts

Optional

Measurement method storage

No

Measurement data storage

No

30 sets

Shear rate

No

yes

Shear stress

No

yes

Motion viscosity calculation

No

Yes (Need to enter density)

11

Timing measurement

No

yes

12

Viscosity curve

Need an external computer

Real-time display of viscosity curve

13

Data, curve printing

Via computer

Optional thermal micro-printer direct printing
