18650 Automatic Insulation Paper Sticking Machine for Battery Pack Assembly18650 Automatic Insulation Paper Sticking Machine for Battery Pack Assembly

18650 Automatic Insulation Paper Sticking Machine for Battery Pack Assembly

  • Model: AOT-IPS-18650
  • Efficiency: About 4500pcs/hour
  • Power: 1600W
  • Warranty: 2 Years
  • Product description: It is an automatic insulating paper sticking machine for 18650 battery baley papar pasting, more effectioncy, it can replace 10-15 staffs works.
  • INQUIRY

Insulation Paper Sticking Machine for 18650 Batteries



Product Application

Design for 18650 battery barley paper sticking.

Suitable for battery pack assembling factory.

Good sticking quality, standard, beautiful appearance, no fall off.

7.5-inch touch screen, PLC programming is easy to operate, comes with fault alarm, can clear the fault according to the prompt.

Large-capacity battery storage bin, can put 450-500 cells in one time

Scraping material collecting system.



Baley Paper Pasting Machine for 18650 Batteries

Voltage Input

AC220V±10%,50HZ±10%

Power

1600W

Range of application

Battery cell positiveand negative insulating barley paper

Barley/Insulation paper thickness

0.1 mml-0.3 mm

Punching Pad Power

0.4 kw variable frequency motor debugging

Control Devices

7.5-inch touch screen, 2-axis stepper motor design, 42-point PLC programmer

Air pressure

0.4-0.8Mpa

Production Efficiency

About 4000-4500pcs/hour

Insulation Paper Pasting Machine

Battery Insulation Paper Sticking Machine

18650 Battery Barley Paper Sticking Machine
